20000W Global-Series CW Fiber Laser

The 20000W High-Power Global Series CW Fiber Lasers developed by Raycus , with high electro-optical conversion efficiency, high light beam quality, high energy density, wide modulation frequency, high reliability, long service life, maintenance-free operation and advantages. The product can be widely applied in welding, precision cutting, melting and cladding, surface processing. Its optical output performance helps it better integrate with robots as a flexible manufacturing equipment to meet processing requirement.
Customer service hotline: 027-81338818 to 8137

Characteristics Of 20000W Global-Series CW Fiber Laser

Technical characteristics
  • High Electro-optical Conversion Efficiency
  • Customized Output Fiber Length
  • Output cable:QP
  • Maintenance-free Operation
  • Wide Modulation Frequency Range
Optical Properties
  • Average output power: (W): 20000
  • Central wavelength: (nm): 1080±5
  • Maximum modulation frequency: (kHz): 2
  • Output power stability: ±1.5%
  • Red laser: Yes
Electronic control characteristics
  • Input power (V AC ): 323-436, Three Phase-four Wire Connect.@47-63Hz
  • Control mode: RS232, AD,Ethernet
  • power adjustment range (%): 10-100
Other characteristics
  • Dimensions (mm ): 960*1530*1160(handle included)
  • Weight (kg): <700
  • Cooling method: water cooling
  • Working temperature (℃ ): 10-40
